Accelerometers

General Purpose Analysis

Monitran General Purpose Analysis Sensors are ideal for use with portable and on-line vibration analysers, providing the user with a complete spectrum of vibration intensity against frequency. Changes in this spectrum allow the user to determine the health of the machinery to which the sensor is attached. Most analysers will store the spectral values and monitor changes over a period of time, allowing prediction of expected component life and enabling efficient planning of maintenance schedules.

This type of information is required in a wide range of environments so while the basic output is common to all sensors in this category there are many variations allowing them to be used in those different environments ranging from:

  • standard industrial conditions
  • submersible and long term wet operation
  • approved under ATEX, IECEx and ANZEx for use in hazardous areas
  • restricted access locations

Two series are available: our long-standing, tried and trusted 1100 range and the newly available 2200 range with enhanced performance for more demanding applications. The 2200 series sensors feature high performance electronics giving:

  • increased shock resistance eliminating signal interruption during high shock loading episodes
  • a stable bias across the temperature range eliminating sensitivity changes at high temperature

MTN/1100, C

MTN/1100 vibration sensorGeneral purpose top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments.
Sealed to IP67 and includes 2-pin MS connector or integral stainless overbraided ETFE cable and is available with a wide range of mountings.

MTN/1100C  MTN/1100

MTN/1100I, C

MTN/1100I hazardous area accelerometerATEX and IECEx Group I & II certified. General purpose top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments.

Sealed to IP67 and includes 2-pin MS connector or integral stainless overbraided ETFE cable and is available with a wide range of mountings.

MTN/M1100IC  MTN/M1100I  MTN/1100IC  MTN/1100I

MTN/1100W

MTN/1100W waterproof vibration sensorSubmersible, general purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/1100W

MTN/1100IW

MTN/1100IW hazardous area waterproof vibration sensorATEX and IECEx Group II certified. Submersible, general purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/1100IW

MTN/1100S, C

MTN/1100S side entry accelerometerGeneral purpose, side-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments.
Sealed to IP67 and includes 2-pin MS connector or integral stainless steel overbraided ETFE cable and ¼”-28 UNF, M6 or M8 mounting bolt.

MTN/1100SC  MTN/1100S

MTN/1100IS, C

MTN/1100IS hazardous area side entry accelerometerATEX and IECEx Group I & II certified. General purpose side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments.
Sealed to IP67 and includes 2-pin MS connector or integral stainless steel overbraided ETFE cable and ¼”-28 UNF, M6 or M8 mounting bolt.

MTN/M1100ISC  MTN/M1100IS  MTN/1100ISC  MTN/1100IS

MTN/1100SW

MTN/1100SW waterproof side entry sensorSubmersible, general purpose, side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 and includes integral heavy duty polyurethane cable and ¼”-28UNF, M6 or M8 mounting bolt.

MTN/1100SW

MTN/1100ISW

MTN/1100ISW hazardous side entry waterproof vibration sensorATEX and IECEx Group II certified. Submersible, general purpose, side-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 and includes integral heavy duty polyurethane cable. ¼”-28UNF, M6 and M8 mounting bolts also available.

MTN/1100ISW

MTN/2200, 4P, C

MTN/2200 accelerometerGeneral purpose top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2200-4P  MTN/2200C  MTN/2200

MTN/2200I, 4P, C

MTN/2200I hazardous area accelerometerATEX and IECEx Group I & II certified. General purpose top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/M2200IC  MTN/M2200I  MTN/2200IC  MTN/2200I-4P  MTN/2200I

MTN/2200W

MTN/2200W waterproof vibration sensorSubmersible, general purpose, top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/2200W

MTN/2200IW

MTN/2200IW hazardous area waterproof accelerometerATEX and IECEx Group II certified. Submersible, general purpose, top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/2200IW

MTN/2200S, 4P, C

MTN/2200S side entry vibration sensorGeneral purpose, side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2200SC  MTN/2200S-4P  MTN/2200S

MTN/2200IS, 4P, C

MTN/2200IS hazardous area side entry accelerometerATEX and IECEx Group I & II certified. General purpose side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2200ISC  MTN/2200IS-4P  MTN/2200IS

MTN/2200SW

MTN/2200SW side entry waterproof vibration sensorSubmersible, general purpose, side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/2200SW

MTN/2200ISW

MTN/220ISW hazardous area side entry waterproof accelerometerATEX and IECEx Group II certified. Submersible, general purpose, side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation. Internal electronics are isolated to minimise noise with increased bias voltage stability
Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/2200ISW

MTN/1107I, IC

MTN/1107I vibration sensorATEX and IECEx Group I & II certified. General purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments. 3 wire device, requires 24V supply.

Sealed to IP67 and includes 3-pin 62GB connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings

  • Environment: Industrial, Hazardous, *Mining
  • Frequency Range: 0.8Hz - 12kHz
  • Temperature Range: -55°C – 140°C
  • Output: AC 100mV/g
  • Entry Type: Top Entry

MTN/1109I, IC

MTN/1109I sensorATEX and IECEx Group I & II certified. General purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments. 3 wire device, requires -24V supply.

Sealed to IP67 and includes 3-pin 62GB connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

  • Environment: Industrial, Hazardous, *Mining
  • Frequency Range: 0.8Hz - 12kHz
  • Temperature Range: -55°C – 140°C
  • Output: AC 100mV/g
  • Entry Type: Top Entry
MTN/1109IC MTN/1109I

MTN/1107, C

MTN/1107 sensorGeneral purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. 3 wire device, requires 24V supply.

Sealed to IP67 and includes 3-pin 62GB connector or integral stainless overbraided ETFE cable and is available with a wide range of mountings.

  • Environment: Industrial
  • Frequency Range: 0.8Hz - 12kHz
  • Temperature Range: -55°C – 140°C
  • Output: AC 100mV/g
  • Entry Type: Top Entry
MTN/1107C

MTN/1109, C

MTN/1109 sensorGeneral purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. 3 wire device, requires -24V supply.

Sealed to IP67 and includes 3-pin 62GB connector or integral stainless steel overbraided ETFE cable and is available with a wide range of mountings.

  • Environment: Industrial
  • Frequency Range: 0.8Hz - 12kHz
  • Temperature Range: -55°C – 140°C
  • Output: AC 100mV/g
  • Entry Type: Top Entry
MTN/1109C MTN/1109

General Purpose Monitoring

Monitran General Purpose Monitoring Sensors are for use with PLC’s and other industrial controllers to provide the user with a continuous output of vibration usually as a 4-20mA signal. Changes in the monitor signal will allow the user to spot vibration changes in the part of the machine to which the sensor is attached. Rapid changes accompany such conditions as machinery working loose from its mountings, fan blade malfunction, bearing failure all of which require immediate attention and machine shutdown to avoid widespread damage and loss of machine time. If the signal is logged at regular intervals, gradually increasing vibration indicates wear in the part of the machine where the sensor is fitted calling for replacement or detailed study with a portable vibration analyser.

This type of information is required in a wide range of environments so while the basic output is common to all sensors in this category there are many variations allowing them to be used in those different environments ranging from:

  • standard industrial conditions
  • submersible and long term wet operation
  • approved under ATEX, IECEx and ANZEx for use in hazardous areas

Two series are available: our long-standing, tried and trusted 1185 and 1187 ranges and the newly available 2285 and 2287 range with enhanced performance for more demanding applications. 2285 and 2287 series sensors feature redesigned electronics plus an internal Faraday shield giving:

  • much reduced noise and interference in real industrial environments
  • improved isolation and easier connection

MTN/1185, C

MTN/1185 vibration transducer General purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments.
Sealed to IP67 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes 3-pin 62GB connector, 2-pin MS connector or integral stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/1185C  MTN/1185

MTN/1185I, C

MTN/1185I hazardous area velocity transducerATEX and IECEx Group I & II certified. General purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh industrial environments.
Sealed to IP67 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral stainless overbraided ETFE cable and is available with a wide range of mountings.

MTN/M1185IC  MTN/1185IC

MTN/1185W

MTN/1185W waterproof velocity sensorSubmersible, general purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/1185W

MTN/1185IW

MTN/1185IW hazardous area waterproof velocity transducerATEX and IECEx Group I & II certified. Submersible, general purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/1185IW

MTN/1187, C

MTN/1187 vibration sensorGeneral purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments.
Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes 3-pin 62GB connector, 2-pin MS connector or integral stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/1187C  MTN/1187

MTN/1187W

MTN/1187W waterproof vibration sensorGeneral purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments.
Sealed to IP68 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/1187W

MTN/1187IC

MTN/1187IC hazardous area velocity sensorATEX and IECEx Group I & II certified. General purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh industrial environments.

Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/1187IC

MTN/1187IW

MTN/1187IW hazardous area velocity transducerATEX and IECEx Group II certified. Submersible, general purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/1187IW

MTN/2285-2P, 4P, C

MTN/2285 velocity sensorGeneral purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.

Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2285C  MTN/2285-4P  MTN/2285-2P

MTN/2285I-2P, 4P, C

MTN/2285I hazardous area velocity transducerATEX and IECEx Group I & II certified. General purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh industrial environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.
Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.

Includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/M2285IC  MTN/2285IC  MTN/2285I-4P  MTN/2285I-2P

MTN/2285W

MTN/2285W waterproof velocity sensorSubmersible, general purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh underwater environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.
Sealed to IP68 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/2285W

MTN/2285IW

MTN/2285IW hazardous area waterproof velocity transducerATEX and IECEx Group II certified. Submersible, general purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh underwater environments and areas with constant moisture or condensation. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.

Sealed to IP68 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.
Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/2285IW

MTN/2287-2P, 4P, C

MTN/2287 velocity transducerGeneral purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.

Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.

Includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2287C  MTN/2287-4P  MTN/2287-2P

MTN/2287I-2P, 4P, C

MTN/2287I hazardous area velocity sensorATEX and IECEx Group I & II certified. General purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.

Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.

Includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2287IC  MTN/2287I-4P  MTN/2287I-2P

MTN/2287W

MTN/2287W waterproof sensorGeneral purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise.
Sealed to IP68 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.

Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/2287W

MTN/2287IW

MTN/2287IW hazardous area waterproof transducerATEX and IECEx Group II certified. Submersible, general purpose, top-entry accelerometer with DC output proportional to acceleration. Made from robust stainless steel throughout for continuous vibration monitoring in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers.

Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/2287IW

Special Purpose

Monitran Special Purpose Sensors extend the range of vibration analysis and monitoring tasks that can be undertaken by modifying the design or sensor type. Thus, models can be selected that can:

  • work at more elevated temperatures
  • work at lower frequencies
  • measure different vibration parameters
  • permit simultaneous measurement of temperature
  • permit more than one vibration parameter to be measured simultaneously by the same sensor

Monitran has a wide range of special sensors many of which can be found in the categories on the left. Monitran’s bespoke design capabilities can be called on to provide almost any combination of sensor style, operating environment and output or combined outputs.

MTN/1010

MTN/1010General purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Includes 25mm base, integral TNC connector and available with a wide range of mountings. Uses coaxial cable (not twin core shielded like the 1100 which also has internal shielding and isolated electronics) and thus shows lower immunity to electrical interference.

MTN/1010

MTN/1020

MTN/1020General purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Includes 19mm base, integral TNC connector and available with a wide range of mountings. Smaller and lighter than MTN/1010. Uses coaxial cable (not twin core shielded like the 1100 which also has internal shielding and isolated electronics) and thus shows lower immunity to electrical interference.

MTN/1020

MTN/1100T, C

MTN/1100Dual purpose, top-entry, constant current accelerometer with isolated AC(g)  and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments.
Sealed to IP67 and includes 62GB 3-pin connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/1100TC  MTN/1100T

MTN/1105CE

MTN/1105CETop-entry, constant current accelerometer for vibration analysis at elevated temperatures. Made from robust stainless steel throughout for long term analysis in harsh environments and up to 250ºC surface temperature; as the sensor head contains no electronics. An in-line charge amplifier connected with extra high-temperature cable (265ºC) can be located 5 metres from the heat source where temperatures are 120ºC or less.

Request details

MTN/1105SCE

MTN/1105SCESide-entry, constant current accelerometer for vibration analysis at elevated temperatures. Made from robust stainless steel throughout for long term analysis in harsh environments and up to 250ºC surface temperature; as the sensor head contains no electronics. An in-line charge amplifier connected with extra high temperature cable (265ºC) can be located 5 metres from the heat source where temperatures are 120ºC or less.

Request details

MTN/1310

MTN/1310Ideally suited to any application where vibration in all three spatial axes needs to be measured, the MTN/1310 is supplied with an integral over-braided 4-core cable and three charge amplifiers encapsulated in a single die cast enclosure.

MTN/1310

MTN/1330

MTN/1330General purpose top-entry constant current accelerometer with 3 isolated AC outputs (X,Y and Z axes) and a 4 pin M12 connector. Internal electronics are isolated to minimise noise with increased bias voltage stability. Ideal for any application where vibration in all three spatial axes needs to be measured.

MTN/1330

MTN/1600, C

MTN/1600General purpose, top-entry, constant current velocity sensor with isolated AC output. Sealed to IP67 and includes 62GB 3-pin connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/1600  MTN/1600C

MTN/1800

MTN/1800Lightweight, small footprint, constant current, high sensitivity accelerometer with lightweight PVC cable.

MTN/1800

MTN/2200T-4P, C

MTN/2200TGeneral purpose top-entry constant current accelerometer with isolated AC and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2200T-4P

MTN/2200IT-4P, C

MTN/2200ITATEX and IECEx Group II certified. General purpose top‐entry constant current accelerometer with isolated AC and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in
harsh, hazardous gas and dust environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2200ITC  MTN/2200IT-4P

MTN/1100STC

MTN/1100STCDual purpose, side-entry, constant current accelerometer with isolated AC(g) and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments.
Sealed to IP67 and includes stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/1100STC

MTN/2200STC

MTN/2200STCDual purpose, side-entry constant current accelerometer with isolated AC and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Internal electronics are isolated to minimise noise with increased bias voltage stability.
Sealed to IP67 and includes stainless steel overbraided ETFE cable. Available with a wide range of mountings.

MTN/2200STC

MTN/1100TW

MTN/1100TWSubmersible, dual purpose, top-entry, constant current accelerometer with isolated AC(g) and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 and includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/1100TW

MTN/2200TW

MTN/2200TWSubmersible, dual purpose, top-entry, constant current accelerometer with isolated AC(g) and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation.
Sealed to IP68 and includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

MTN/2200TW

MTN/2285IT-4P, C

MTN/2285ATEX and IECEx Group II certified. General purpose, top‐entry velocity transducer with DC and temperature outputs. Made from robust stainless steel throughout for continuous vibration monitoring in harsh industrial environments.
Sealed to IP67 with industry standard two‐wire 4‐20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers. Includes 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

MTN/2285IT,C MTN/2285IT-4P

MTN/2285STC

MTN/2285STCDual purpose, side-entry, velocity transducer with DC and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments.
Sealed to IP65 and includes stainless steel overbraided ETFE cable and ¼”-28 UNF, M6 or M8 mounting bolt.

MTN/2285STC

MTN/7000 Series

MTN/7000The 7000 series uses piezo-resistive sensor elements which operate well at low frequencies, from 0Hz to a few hundred Hz depending upon the chosen operating range. Their low frequency response allows them to be used to measure the very slow vibrations in massive structures

MTN/7200 MTN/7100 MTN/7000

MTN/P Series

MTN/PCharge output accelerometers

MTN/P1100 MTN/P100 MTN/P50 MTN/P05

MTN/1170

MTN/1107Small footprint, general purpose, top-entry constant current accelerometer with an isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Sealed to IP67 and includes 2-pin C5015 military style connector. Available with a wide range of mountings and 19mm diameter base.

MTN/1170

MTN/1120, C

MTN/1120Small footprint, general purpose, top-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Sealed to IP67 and includes 3-pin 62GB style connector or stainless overbraided ETFE cable. Available with a wide range of mountings and 19mm diameter base.

MTN/1120C MTN/1120

MTN/1120SC

MTN/1120SCSmall footprint, general purpose, side-entry, constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Sealed to IP67 and includes stainless overbraided ETFE cable. Available with a wide range of mountings and 19mm diameter base and 24mm high.

MTN/1120SC

MTN/1130

MTN/1130Small footprint, general purpose, top-entry constant current accelerometer with an isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Specially adapted for use on light weight, high speed machinery. Sealed to IP67 and includes integral stainless overbraided ETFE cable available with a wide range of mountings including quick release, swivel base. Ultra-slim 15mm body.

MTN/1130

MTN/1135C

MTN/1135CSmall footprint, general purpose, side-entry constant current accelerometer with an isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Specially adapted for use on light weight, high speed machinery. Includes Sealed to IP67 and includes integral stainless overbraided ETFE cable with quick release, swivel base. Ultra-slim 15mm body and only 25mm high, ideal for use in restricted areas.

MTN/1135C

MTN/1140

MTN/1140Small footprint, general purpose, top-entry constant current accelerometer with an isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Specially adapted for use on light weight, high speed machinery. Sealed to IP67 and includes integral stainless overbraided ETFE cable available with male, female and conical mountings. Ultra-slim 15mm body.

MTN/1140

MTN/1830SC

MTN/1830SCLow profile, general purpose, side-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments with restrictive access. Sealed to IP67 and includes stainless steel overbraided ETFE cable and ¼”, M6 or M8 mounting bolt.

MTN/1830SC

MTN/1186, C

MTN/1186Dual purpose, top-entry, accelerometer with 100mV/g AC and 4-20mA DC outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Sealed to IP67 and includes 62GB 3-pin connector or integral stainless overbraided ETFE cable. Available with a wide range of mountings.

MTN/1186C MTN/1186

MTN/1186W

MTN/1186WSubmersible dual purpose, top-entry, accelerometer with 100mV/g AC and 4-20mA DC outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments and areas with constant moisture or condensation. Sealed to IP68 and includes heavy duty polyurethane cable. Available with a wide range of mountings.

MTN/1186W

MTN/1188, C

MTN/1188CDual purpose, top-entry, accelerometer with 100mV/g AC and 4-20mA DC outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Sealed to IP67 and includes 62GB 3-pin connector or integral stainless overbraided ETFE cable. Available with a wide range of mountings.

MTN/1188C MTN/1188

call us on +44 (0) 1494 816569

Monitran Product Range

accelerometers

Accelerometers

Ideal for use with portable and on-line vibration analysers.

monitoring systems

Monitoring Systems

Monitoring systems that can be used to measure vibration.

enclosures

Enclosures

Switch Enclosures and Connection Enclosures by Monitran.

linear variable differential transformer

LVDT's

LVDT'S are a popular tansducer in industrial applications.

eddy current probes and drivers

ECPD

The latest precision-wound copper coil Proximity Sensors.

accessories

Accessories

Allowing the user access to a vibration sensor for machinery.


Established in 1986, Monitran remains a privately owned company, based near High Wycombe 35 miles west of London.

We manufacture in the United Kingdom and source the majority of our materials and components from selected quality-managed local and national suppliers.

Call Us: +44 (0)1494 816569

Monitor House
33 Hazlemere Road
Penn
HP10 8AD
UK
